Description
FPR-4/12X Fiber Optic Panel (4RU)
The TXM FPR Series is a family of rack-mounted fiber distribution enclosures that provides splicing and patching of fiber optic terminations using industry-standard LGX adapter plates or MPO/MTP cassettes. Panels can be ordered empty or pre-configured to your specifications. All FPR panels feature front- and rear-latching doors and slide-out trays with stops to prevent stress on delicate fibers. Reversible rack ears allow mounting in either 19- or 23-inch racks.
The TXM FPR-4/12X is a four Rack Unit (4RU) panel that accomodates 12 standard LGX adapter plates (sold separately or pre-configured). It features front Plexiglas and rear metal doors to allow easy access.
Technical Specifications
Dimensions: 7.0"(h )x 17.0"(w) x 14.0"(d) / 17.78cm(h) x 43.18"(w) x 35.56cm(d)
Splice Trays: Holds up to Eight Splice Trays with 12 or 24 splice capability for a total of 192 possible splices
**Note: This item is SOLD SEPERATELY. (SKU: FP-SPLC-TRAY-01 and FP-SPLC-TRAY-02)
Material: 16 Gauge Powder Coated Steel
Coating: Electrostatic polyester powder coat paint (available in standard black). Other colors available for bulk orders.
Capacity
- The unit can support paching and splicing
- Terminations: (12) TXM Adapter Plates (see individual plate capacities)
- Splices: Up to 96 single fused fiber splices using four FP-SPLC-02 splice trays
Product Ordering Information
- Model Number: FPR-4/12X
- Loaded and unloaded adapter plates sold separately
INCLUDES SPLICE TRAY AND SPLICE WHEEL
